Fonweld HF600
FONWELD HF600
Type – Hardfacing electrode with rutile coating.
DIN 8555: E 6-UM-55
Applications:
- Build-up of worn parts subject to wear by abrasion and at the same time to shocks. For worn parts of farming equipment, excavator teeth, worm screws, crusher jaws, forestry tools, concrete mixer blades, crushing heads, stamping, sliding and guide rails, etc.
Characteristics:
- HF600 is a chromium-alloyed electrode. It deposits a very smooth and even beads. The beads can be weaved. Good slag detachability. The resistance to abrasive wear is very good.
Current Mode: AC / DCEP
Chemical analysis of weld deposit, typical values in %:
| C | Mn | Si | Cr | Mo | Fe |
| 0.40 | 0.50 | 0.40 | 6.00 | 0.60 | Balance |
Mechanical properties:
Weld metal hardness, a w: 54-58 HRC
Machinability: Grinding only
Abrasion resistance: Very good
Welding current:
mm Amps
2.5 x 350 60-120
3.25 x 350 90-120
4.0 x 450 125-210
5.0 x 450 160-260
Specifications
| SKU | FONWELD HF600 |
|---|
