Hugong Superwave 315 Ac/Dc Tig
- IGBT Inverter control square wave technology
- Integration of DC TIG Welding, AC TIG Welding, AC/DC TIG Welding
- and manual ARC welding
- Suitable for aluminium, magnesium, and all alloy welding
- Available in air cooling or water cooling
- 2 step or 4 step control
- Optional for remote control
- Generator friendly
- Recommended for fabrication of stainless steel and aluminium using the manual metal ARC and TIG processes
Standard Accessories
- TIG torch
- 4 m earth cable with clamp and quick connector
- 4m gas hose with hoop and connector
- Other (Switch, tungsten stick, collet, back caps, etc)
Specifications
| AC/DC | AC/DC |
|---|---|
| AC/DC | AC/DC |
| 100% welding current (A) | 244 |
| Welding current adjustment range (A) | 15-315 |
| Duty cycle at 60% welding current (A) | 315 |
| Rated open circuit voltage (V) | 64 |
| Power input (V) | 400 |
| Rated input capacity (KVA) | 9 |
| Rated input current (A) | 19 |
| Weight (kg) | 75.0 |
| SKU | HUGONG SUPERWAVE 315 AC/DC TIG |
